When using the product, the inputs and outputs of the module must be isolated from the ground.
Specifications:
Input voltage range:- 638VDC (note: input voltage not higher than 38V)
Output voltage range:- adjustable from 1.25-36VDC
Output current:- 0-5 a
Output power:- 75W
Input reverse polar protection:- None (if necessary, high current diode in series with the input).
Features:
High efficiency up to 96%
Integrated thermal shutdown function
Built-in current limit function
Built-in short output protection function
Use:
Adjust the voltage potentiometer “” so that the output voltage reaches the desired value.
Use a multimeter to measure the output short-circuit current with positions 10A, while adjusting the current potentiometer "" so that the output current reaches a predetermined protection value. (For example, the meter shows the current value of 4A, so you can use the module with a maximum current of 4A)
